* COMING SOON * 300 W X 4CH DSP PRO WATERPROOF AMPLIFIER
Regular price
$1,099.99
Sale price
Regular price
Coming Soon!
Drop your email below, and we'll let you know when they're live!
FEATURES
CONTROL YOUR SOUND LIKE A TOTAL PRO
SPECIFICATIONS
OUTPUT POWER
CONTROL YOUR SOUND LIKE A TOTAL PRO
- Precise DSP control with DIALD™ software, engineered by Cicada Audio®
- Supports DIALD™ DSP Configuration Software for Windows® PC & iOS® / Android™ App compatibility
- Bluetooth® connectivity for DSP App tuning and supported audio streaming
- USB-C input port for PC tuning (requires data-capable USB-C cable [included]; charging-only cables not supported)
- Built-in 6-channel DSP processor (4 amplified, 2 pass-through)
- 2 / 4 channel input switch control
- Fully bridgeable into 2 channels @ 4 Ω
- DSP selectable HP / BP / LP crossovers with 6 / 12 / 24 / 48 dB per octave slopes
- Sensitivity adjustment from 12 V –2 V
- Clipping and Status LED indicators
- Compact and engineered to deliver maximum power without compromise
- 1200 W of high-fidelity power in a chassis that fits in your fairing
- Class D IR-based chipset offers latest in digital technology
- Designed for easy mounting with 2014-2023 or 2024 and newer H-D® Road Glide® or Street Glide® amplifier racks [not included]
- Multiple directional mounting options with included brackets
- Molex® inputs for flexible hookup via RCA or H-D® custom termination
- Multiple remote turn-on configuration options (REM / DC / VOX)
- Rugged IPX6 waterproof design built to handle extreme water exposure
- Water-repellent materials with over‑molded strain relief for enhanced durability
- Protective conformal coating applied to the circuit board guards against moisture, vibration, and environmental exposure
- Fully encased in extruded aluminum heatsink for efficient thermal management
- CAD circuit provides superior overload protection
- Premium busbar style connections: 4 AWG power / ground and 12 AWG speaker wires
- Three (3) year warranty
SPECIFICATIONS
OUTPUT POWER
- RMS Power Output – 4 Channel (14.4 V): 200 W x 4 @ 4 Ω Stereo | 300 W x 4 @ 2 Ω Stereo
- RMS Power Output – 2 Channel Bridged Mode (14.4 V): 600 W x 2 @ 4 Ω
- Frequency Response: 20 Hz – 20 kHz +/- 3 dB
- THD + N (10% Rated Power): 0.1% @ 2 Ω per channel
- Signal-to-Noise Ratio: 91 dB (A-weighted)
- Damping Factor: 200
- Total Efficiency: 80%
- Crossover Modes: HP / BP / LP
- Crossover Frequency Range: 20 Hz – 20 kHz
- Crossover Slope (DSP selectable): 6 / 12 / 24 / 48 dB per octave
- Gain Range: 12 V – 0.2 V
- Operating Voltage: 9 V – 16 V
- Current Draw (Music): 70 A
- Current Draw (Max): 150 A
- Recommended Fuse (Music): 100 A
- Turn-On Configuration: REM / DC / VOX
- Dimensions (with mounting brackets): 8.8 x 5.1 x 2.1 inch (223 x 130 x 52 mm)
- Dimensions (chassis only): 7.6 x 5.1 x 2.1 inch (192 x 130 x 52 mm)
