5000W x 1 MONO CLASS D AMPLIFIER - 1 OHM * COMING SOON *
Regular price
$999.99
Sale price
Regular price
Coming Soon!
Drop your email below, and we'll let you know when they're live!
FEATURES
Compact size engineered to never compromise, and always deliver the most powerful output
Included mounting brackets for secure installation
Class D lR® chipset offers latest in digital technology
Conformal coated layer applied over the circuit board for protection against various environmental conditions
CAD circuit provides superior overload protection
Premium 1/0 AWG power and 12 AWG speaker busbar style inputs/outputs for solid connections
Molex® inputs for flexible hook up via RCA or H-D® custom termination
Clipping and Status LED indicators
Sensitivity adjustment from 12v-0.2v
Fully encased in extruded Aluminum heatsink
Two (2) year warranty
SPECIFICATIONS
RMS Power Output @ 14.4v: 3000W x 1 @ 4Ω, 5000W x 1 @ 1Ω
SNR: 86 dB (A-weighted, 20 Hz- 250 Hz)
Operating Voltage: 9V – 16V
Current Draw (Music): 200 A
Current Draw (Max): 450 A
Recommended Fuse (Music): 200 A
Total Efficiency: 80%
Frequency response 20 Hz – 250 Hz +/- 3 dB
Damping Factor: 200
Crossover LPF: 20 – 250 Hz
Subsonic: 20 – 50Hz
Slope: 12 dB per octave
Compact size engineered to never compromise, and always deliver the most powerful output
Included mounting brackets for secure installation
Class D lR® chipset offers latest in digital technology
Conformal coated layer applied over the circuit board for protection against various environmental conditions
CAD circuit provides superior overload protection
Premium 1/0 AWG power and 12 AWG speaker busbar style inputs/outputs for solid connections
Molex® inputs for flexible hook up via RCA or H-D® custom termination
Clipping and Status LED indicators
Sensitivity adjustment from 12v-0.2v
Fully encased in extruded Aluminum heatsink
Two (2) year warranty
SPECIFICATIONS
RMS Power Output @ 14.4v: 3000W x 1 @ 4Ω, 5000W x 1 @ 1Ω
SNR: 86 dB (A-weighted, 20 Hz- 250 Hz)
Operating Voltage: 9V – 16V
Current Draw (Music): 200 A
Current Draw (Max): 450 A
Recommended Fuse (Music): 200 A
Total Efficiency: 80%
Frequency response 20 Hz – 250 Hz +/- 3 dB
Damping Factor: 200
Crossover LPF: 20 – 250 Hz
Subsonic: 20 – 50Hz
Slope: 12 dB per octave
