FLX1400.4P
350w x 4CH DSP PRO AMPLIFIER *DISCONTINUED*
Discontinued
This product has been discontinued
It is no longer available for purchase, but we still support it. If you have questions or need help, our team is here for you.
Check out the newer model
350w x 4CH DSP PRO AMPLIFIER
Contact Us
4 CHANNEL DSP POWER AMPLIFIER
Requires 4 AWG Power Wire - HDPG4K- 4 X 200 WRMS into 4 ohms @ 12.5 Vdc
- 4 X 225 WRMS into 4 ohms @ 14.4 Vdc
- 4 X 300 WRMS into 2 ohms @ 12.5 Vdc
- 4 X 350 WRMS into 2 ohms @ 14.4 Vdc
BRIDGED MONO - 2 CHANNEL
- 2 X 600 WRMS into 4 ohms @ 12.5 Vdc
- 2 X 700 WRMS into 4 ohms @ 14.4 Vdc
- Frequency response - 20-20,000 +/- 3dB THD < 0.5%
- Operating Voltage: 8 V – 16 V
- Current Draw (Music): 50 A
- Current Draw (Max): 220 A
- Recommended Fuse (Music): 120 A
- Total Efficiency: 79%
- Damping Factor: 200
- SNR: 91 dB
- Crossover LPF/FULL/HPF: 30 TO 300Hz
- Slope:12dB per octave
- Gain: 0.2V - 12 Vac
- Turn-On Configuration: REM/DC
- DSP Crossover HPF/LPF: 0 TO 20kHz
- Slope configurable 6/12/18/24/48dB
- DSP PEQ – 8 BANDS
- Q’s Adjustable from 0.05 – 20
- THD + N (10% Rated Power): 0.1%
- Product Dimensions (Inches / Millimeters): overall - 8.25 x 4.9 x 2.0 in / 209.55 x 125 x 51 mm chassis only - 7 x 4.9 x 2.0 in / 177.8 x 125 x 51 mm
